Murrelektronik
T-Coupler M8 Nano male / 2x female A-cod.
Price excluding VAT
Request a quote
T-coupler (Nano) Male straight – females straight M8 – M8, 4-pole Distribution function (NO) Plastic housings with good resistance against chemicals and...
Weight
0,014 kg
Country of origin
DE
Model designation
MSA02TL0-BR-BR Nano
Family construction form
M8
No. of poles
4
Coding
A
Gender
male
Mounting method
inserted, screwed, Shaking protection
Tightening torque
0,4 Nm
Width across flats
SW9
Cable outlet
straight
Degree of protection (EN IEC 60529)
IP67
Operating voltage AC max.
32 V
Operating voltage DC max.
32 V
Current operating per contact max.
2 A
