Murrelektronik
T-Coupler M12 male/ M12 male w.cable+female A-cod.
Price excluding VAT
Request a quote
AIDA conform T-coupler (Slim Line) Male straight – female/male straight M12 – M12, 2-pole Connection cable 0.2 m Distribution function (NO) for Cube67...
Weight
0,035 kg
Country of origin
DE
Model designation
MSA01PL0-BT-AP633_0.2-S30
Family construction form
M12
No. of poles
4
Coding
A
Gender
male
Mounting method
inserted, screwed
Threaded hole
M12 x 1
Tightening torque
0,6 Nm
Width across flats
SW13
Cable outlet
straight
Degree of protection (EN IEC 60529)
IP67
Operating voltage AC max.
60 V
Operating voltage DC max.
60 V
