Murrelektronik
T-Coupler Slimline M12 female / 2x M12 male A-cod.
Prix hors TVA
Demander un devis
T-coupler (Slim Line) Female M12 5-pole Male M12 2-pole 3-pole Plastic housings with good resistance against chemicals and oils. The resistance to aggressive...
Poids
0,030 kg
Pays d'origine
DE
Désignation du modèle
MSB01UL0-AR-AP
Family construction form
M12
Coding
A
Mounting method
inserted, screwed, Shaking protection
Width across flats
SW13
Material contact
Copper alloy
Operating voltage AC max.
30 V
Operating voltage DC max.
30 V
Current operating per contact max.
4 A
Tightening torque
0,6 Nm
Mounting set
M12 x 1
Degree of protection (EN IEC 60529)
IP67
Additional condition protection degree
inserted, screwed
