MVP12 plastic DI16 IO-Link I/O module
Price excluding VAT
Request a quote
Compact module IO-Link V1.1 Connection cables are in the online shop under "Connection Technology". Housing fully potted.
Weight
0,200 kg
Country of origin
CZ
Model designation
MVP12 DI16 IOL
Input filter time
1 ms
Type input
PNP (EN 61131-2) Type 3
IO-Link type
Device
Port Class
A
IO-Link revision ID
V1.1
IO-Link transmission rate
COM2 (38.4 kbit/s)
IO-Link cycle time min.
2,3 ms
Short circuit diagnosis
Yes
Overload diagnosis
Yes
Diagnostic via LED
per module and channel
LED display
Ethernet connection/data traffic
IO-Link events
Undervoltage supply, No voltage
