IO-Link hub in 30 mm plastic housing 1 × M12 IO-Link Class A 8 × M8 I/O 8 configurable digital inputs/outputs Preconfigured parameter range Connection...
Weight
0,129 kg
Country of origin
DE
Model designation
MVP8-P3 DIO8 8xM8-3 IOLA12 B0
Operating voltage DC
24 V
Operating voltage US DC
24 V
Total current US max.
4 A
Current consumption max.
40 mA
Current operating per 2 ports max.
1 A (X0+X1, X2+X3, X4+X5, X6+X7)
Input filter time
1 ms
Type input
Type 3, Type 1
Output current per pin max.
0,5 A
IO-Link type
Device
Port Class
A
IO-Link revision ID
V1.1.2
IO-Link transmission rate
COM3 (230.4 kbit/s)
