Murrelektronik
MVP12-P6 DIO8 DIO8 8xM12A IOLA12 PL4 E0
Price excluding VAT
Request a quote
IO-Link hub in 50 mm plastic housing 16 configurable digital inputs/outputs 1 × M12 IO-Link Class A 1 × M12L 4-pin power port with galvanic isolation 8 ×...
Weight
0,200 kg
Country of origin
DE
Model designation
MVP12-P6 DIO8 DIO8 8xM12A IOLA12 PL4 E0
Operating voltage DC
24 V
Operating voltage UL1 DC
24 V
Operating voltage UL1 DC min.
18 V
Operating voltage UL1 DC max.
30 V
Total current UL1
6 A
Operating voltage UL2 DC
24 V
Operating voltage UL2 DC min.
18 V
Operating voltage UL2 DC max.
30 V
Total current UL2
6 A
Current consumption max.
75 mA
Sensor current per input max.
0,5 A
Input time filter min.
1 ms
