Murrelektronik
MICO BASIC 4.6 electronic circuit protection, 4 CHANNELS
Prix hors TVA
Demander un devis
MICO BASIC 4.6 4 channels Current adjustment 6 A
Poids
0,090 kg
Pays d'origine
CZ
Désignation du modèle
MICO Basic 4.6
Input voltage DC
24 V
Input voltage DC min.
18 V
Input voltage DC max.
30 V
Total current bridge set max.
40 A
ON input voltage control inputs min.
10 V
ON input voltage control inputs max.
30 V
ON pulse length control inputs high min.
20 ms
Switch-on capacity per channel max.
20 mF
Switching current max.
20 mA
Connection cross-section inputs max.
16 mm²
Connection cross-section outputs max.
4 mm²
Connection cross-section control inputs / control outputs max.
2,5 mm²
