Mico Pro® PM 24 V DC/40 A Cover plate included (heavy duty) Shock load 1/2 sin 40 g, 11 ms Build your own Mico Pro® online: START
Weight
0,193 kg
Country of origin
CZ
Model designation
Mico Pro PM 24VDC/40A
Total current max.
40 A
Input voltage DC min.
9 V
Input voltage DC max.
30 V
Nominal input voltage DC
12 V … 24 V
Total current bridge set max.
40 A
ON input voltage control inputs min.
9 V
ON input voltage control inputs max.
30 V
CTRL signal
ON/OFF
CTRL input voltage control inputs high min.
9 V
CTRL input voltage control inputs high max.
30 V
ON pulse length control inputs high min.
120 ms
Switching voltage AC max.
30 V
