Customized printing and packaging Male straight – female straight M12 – M12, 5-pole with cable sleeves Zinc die casting, save-cover coated Plastic...
Kaal
0,439 kg
Päritoluriik
DE
Mudeli tähistus
MSBL0-A-U658_10.0-XH-DS
Cable length
10,00 m
Family construction form
M12
No. of poles
5
Mounting method
inserted, screwed
Material contact
Copper alloy
Coating contact
gold plated
Operating voltage AC max.
125 V
Operating voltage DC max.
125 V
Pollution Degree
3
Rated surge voltage
1,5 kV
Material group (IEC 60664-1)
I
Operating temperature min.
-25 °C
