Murrelektronik
M12 female recept. 0° L-cod. rear
Price excluding VAT
Request a quote
PCB connectors Female straight M12, 4-pole L-coded Rear mounting THT-solder connection
Weight
0,050 kg
Country of origin
DE
Model designation
MSBFHL0-T-PCB
Family construction form
M12P
No. of poles
4
Coding
L
Material contact
Copper alloy
Coating contact
gold plated
Operating voltage DC
63 V
Current operating per contact max.
16 A
Tightening torque
0,6 Nm
Mounting set
M16 x 1.5
Width across flats
SW19
Connection information
THT-solder connection
Degree of protection (EN IEC 60529)
IP67, IP68, IP65
