Flange female 7/8" (5-pole) with multi-strand wire
Kaal
0,149 kg
Päritoluriik
DE
Mudeli tähistus
7/8''FLANSCHDOSE 5-POL.978 2,0MLITZE
Family construction form
7/8"
No. of poles
5
Gender
female
Mounting method
inserted, screwed, Shaking protection
Threaded hole
7/8"
Tightening torque
1,5 Nm
Width across flats
SW24
Material contact
Brass
Coating contact
gold plated
Degree of protection (EN IEC 60529)
IP68
Operating voltage AC max.
300 V
Operating voltage DC max.
300 V
