Expansion module DIO16 - 1.6 A DO16 - 2 A (E) - 16× M12 Digital inputs/outputs (multifunctional) Connection cables are in the online shop under "Connection...
Kaal
0,600 kg
Päritoluriik
CZ
Mudeli tähistus
Cube67 DIO16 DO16 E 16xM12 (1,6/2A)
Operating voltage DC
24 V
Operating voltage US DC
24 V
Total current US max.
4 A
Total current UA max.
4 A
Current consumption max.
50 mA
Sensor current US per input max.
0,2 A
Short-circuit protected
Yes
Overload resistant
Yes
Input filter time
1 ms
Type input
for 3-wire sensors or mechanical switches, PNP
Current actuator side 1 max.
1,6 A
Current actuator side 2 max.
2 A
