BNS00U3 (BNS 813-D03-D12-100-55-FD-0764) - Mechanical multiple position limit switches with safety switch positions - Housing material: Aluminium, Anodized, Version: Safety EN 60204-1, Operating principle: 1. Switch position: Inductive, 2-3. Switch position: Mechanical, Range: 2 mm, Continuous current: 1. Switch position: 0.2 A, 2-3. Switch position: 6 A, Rated operating voltage Ue: 1. Switch position: 24 V DC, 2-3. Switch position: 250 V AC, Installation: Vertical, Approach direction: longitudinal, parallel to attachment surface, Approach speed: 2-3. Switch position: 40 m/min, Connection type: 1-3. Switch position: Screw terminal, Ambient temperature: -5...70 °C, IP rating: IP67, Approval/Conformity: CE, UKCA, WEEE
