BNS00R8 (BNS 813-D02-D16-100-22-02-FC) - Mechanical multiple position limit switches with safety switch positions - Housing material: Aluminium, Anodized, Number of switching positions: 2x Chisel, Version: Safety EN 60204-1, Operating principle: 1-2. Switch position: Mechanical, Continuous current: 1-2. Switch position: 6 A, Rated operating voltage Ue: 1-2. Switch position: 250 V AC, Installation: Vertical, Approach direction: longitudinal, parallel to attachment surface, Approach speed: 1-2. Switch position: 40 m/min, Ambient temperature: -5...85 °C, IP rating: IP67, Approval/Conformity: CE, WEEE
Housing material
Aluminium, Anodized
Number of switching positions
2x Chisel
Version
Safety EN 60204-1
Operating principle
1-2. Switch position: Mechanical
Continuous current
1-2. Switch position: 6 A
Rated operating voltage Ue
1-2. Switch position: 250 V AC
Installation
Vertical
Approach direction
longitudinal, parallel to attachment surface
Approach speed
1-2. Switch position: 40 m/min
Ambient temperature
-5...85 °C
IP rating
IP67
Approval/Conformity
CEWEEE
Manufacturer
Balluff GmbH
Declaration of Compliance
EU-Konformitätserklärung / EU Declaration of Conformity (CE) | (All languages)
Tariff Code
85365080
Disposal instructions
Download
Manuals, CAD models, certificates and other materials are available on the manufacturer's website:
Open product page on manufacturer's website
