BNS 813-B04-D12-72-55-FD-0456

BNS03R3 (BNS 813-B04-D12-72-55-FD-0456) - Mechanical multiple position limit switches with safety switch positions - Housing material: Aluminium, Anodized, Version: Safety EN 60204-1, Operating principle: 1-3. Switch position: Inductive, 4. Switch position: Mechanical, Range: 2 mm, Continuous current: 1-3. Switch position: 0.2 A, 4. Switch position: 6 A, Rated operating voltage Ue: 1-3. Switch position: 24 V DC, 4. Switch position: 250 V AC, Installation: Vertical, Approach direction: Vertical to mounting surface, Approach speed: 4. Switch position: 40 m/min, Connection type: 1-4. Switch position: Screw terminal, Ambient temperature: -5...70 °C, IP rating: IP67, Approval/Conformity: CE, UKCA, WEEE
