BIS00LC (BIS M-107-03/L-H200) - HF RFID tags (13.56 MHz) - List price Deutschland: 47,50 EUR - Product group: HF (13.56 MHz), Dimension: 22 x 6.5 x 40 mm, Antenna type: round, UID serial number, read-only: 8 Byte, Memory type: EEPROM, Supported data carrier types: DIN ISO 15693, User data, read/write: 112 Byte, Storage temperature: -25...85 °C, Storage temperature temporary: 200 °C 1x1000 h, Ambient temperature: -25...70 °C, Housing material: PPS, GF40, With EP potting, IP rating: IP67, Installation: metal-free (clear zone), Approval/Conformity: CE, UKCA, WEEE
Product group
HF (13.56 MHz)
Antenna type
round
UID serial number, read-only
8 Byte
Memory type
EEPROM
Supported data carrier types
DIN ISO 15693
User data, read/write
112 Byte
Storage temperature
-25...85 °C
Storage temperature temporary
200 °C 1x1000 h
Ambient temperature
-25...70 °C
Housing material
PPS, GF40, With EP potting
IP rating
IP67
Installation
metal-free (clear zone)
Approval/Conformity
CEUKCAWEEE
Manufacturer
Balluff GmbH
Declaration of Compliance
EU-Konformitätserklärung / EU Declaration of Conformity (CE) | (All languages)
Tariff Code
85235200
Substances of concern
Download
Disposal instructions
Download
Manuals, CAD models, certificates and other materials are available on the manufacturer's website:
Open product page on manufacturer's website
