BIS00M8 (BIS M-140-02/A-M8) - HF RFID tags (13.56 MHz) - List price Deutschland: 70,48 EUR - Product group: HF (13.56 MHz), Dimension: Ø 22 x 31 mm, Antenna type: round, UID serial number, read-only: 8 Byte, Memory type: FRAM, Supported data carrier types: DIN ISO 15693, User data, read/write: 2000 Byte, Storage temperature: -25...95 °C, Ambient temperature: -25...70 °C, Housing material: Steel, Data carrier: PA 12-GF30, coated, IP rating: IP68, IPx9K, Installation: metal-free (clear zone), on metal, Approval/Conformity: CE, UKCA, WEEE
Product group
HF (13.56 MHz)
Antenna type
round
UID serial number, read-only
8 Byte
Memory type
FRAM
Supported data carrier types
DIN ISO 15693
User data, read/write
2000 Byte
Storage temperature
-25...95 °C
Ambient temperature
-25...70 °C
Housing material
Steel, Data carrier: PA 12-GF30, coated
IP rating
IP68IPx9K
Installation
metal-free (clear zone)on metal
Approval/Conformity
CEUKCAWEEE
Manufacturer
Balluff GmbH
Declaration of Compliance
EU-Konformitätserklärung / EU Declaration of Conformity (CE) | (All languages)
Tariff Code
85235200
Substances of concern
Download
Disposal instructions
Download
Manuals, CAD models, certificates and other materials are available on the manufacturer's website:
Open product page on manufacturer's website
