BIS004E (BIS M-125-01/L) - HF RFID tags (13.56 MHz) - List price Deutschland: 50,29 EUR - Product group: HF (13.56 MHz), Dimension: 30 x 6 x 30 mm, Antenna type: round, UID serial number, read-only: 4 Byte, Memory type: EEPROM, Supported data carrier types: DIN ISO 14443, User data, read/write: 752 Byte, Storage temperature: -25...85 °C, Ambient temperature: -25...70 °C, Housing material: PBT, IP rating: IP67, Installation: metal-free (clear zone), Approval/Conformity: CE, WEEE
Product group
HF (13.56 MHz)
Antenna type
round
UID serial number, read-only
4 Byte
Memory type
EEPROM
Supported data carrier types
DIN ISO 14443
User data, read/write
752 Byte
Storage temperature
-25...85 °C
Ambient temperature
-25...70 °C
Housing material
PBT
IP rating
IP67
Installation
metal-free (clear zone)
Approval/Conformity
CEWEEE
Manufacturer
Balluff GmbH
Declaration of Compliance
EU-Konformitätserklärung / EU Declaration of Conformity | (All languages)
Tariff Code
85235910
Disposal instructions
Download
Manuals, CAD models, certificates and other materials are available on the manufacturer's website:
Open product page on manufacturer's website
