BCC0JMY (BCC A213-A213-3C-375-EX43T2-040) - Double-ended cordsets - Connection 1: 1/2"-Female, straight, 3-pin, Connection 2: 1/2"-Male, straight, 3-pin, Cable: TPE Yellow, 4.00 m, Drag chain compatible, Number of conductors: 3, Cable temperature, fixed routing: -50...105 °C, Cable temperature, flexible routing: -25...105 °C, Operating voltage Ub: 250 VDC / 250 VAC, Rated current (40 °C): 4.0 A, IP rating: IP67/IP67, Approval/Conformity: cULus, EAC, WEEE
Connection 1
1/2"-Female, straight, 3-pin
Connection 2
1/2"-Male, straight, 3-pin
Cable
TPE Yellow, 4.00 m, Drag chain compatible
Number of conductors
3
Cable temperature, fixed routing
-50...105 °C
Cable temperature, flexible routing
-25...105 °C
Operating voltage Ub
250 VDC / 250 VAC
Rated current (40 °C)
4.0 A
IP rating
IP67/IP67
Approval/Conformity
cULusEACWEEE
Manufacturer
Balluff GmbH
Taric code
85444290
