Murrelektronik
Y-Distributor M8 male / M8 female 0° A-cod.
Hind käibemaksuta
Küsi pakkumist
Y-connector M8 – M8, 4/3-pole Male straight – females straight Art-No. 7005 - M8 Lite - (plastic hexagonal screw) on request Plastic housings with good...
Kaal
0,089 kg
Päritoluriik
DE
Mudeli tähistus
MSHYTL0-FR630_1.5-FR630_1.5
Cable length
1,50 m
Family construction form
M8
Mounting method
inserted, screwed, Shaking protection
Threaded hole
M8 x 1
Tightening torque
0,4 Nm
Width across flats
SW9
suitable for corrugated tube (internal Ø)
6,5 mm
Material contact
Copper alloy
Coating contact
gold plated
Operating voltage AC max.
50 V
Operating voltage DC max.
60 V
Current operating per contact max.
4 A
