Image-based code readers | GLS6 | V2D611G-MMSBE4 | Reading distance: 50 mm ... 300 mm | Overrun speed: ≤ 5 m/s | 2D code types: Data Matrix ECC200, QR code | Enclosure rating: IP54 | Communication interface: Ethernet, PROFINET, EtherNet/IP™, Serial, CAN, CANopen
Optical focus
Adjustable focus (manual)
Illumination
Integrated
Illumination color
Amber, LED, Visible, 617 nm, ± 15 nmBlue, LED, Visible, 470 nm, ± 15 nm
LED class
1 (IEC 62471:2006-07, EN 62471:2008-09)
Feedback spot
LED, Visible, green, 525 nm, ± 15 nmLED, Visible, Red, 635 nm, ± 15 nm
Alignment aid
Laser, Visible, 630 nm ... 680 nm
Laser class
1, complies with 21 CFR 1040.10 except for the conformance according to “Laser Notice No. 50” from June 24, 2007 (IEC 60825-1:2014, EN 60825-1:2014+A11:2021)
Reading distance
50 mm ... 300 mm
Overrun speed
≤ 5 m/s
Accuracy (position)
± 0.1 mm1)
Repeatability (position)
± 0.05 mm1)
Working range
50 mm ... 300 mm
Connection type
1 x M12, 17-pin male connector1 x M12, 4-pin Ethernet female connectorCircular plug-in connector
Supply voltage
12 V AC ... 24 V DC, ± 15 %
Power consumption
Typ. 3.5 W
Output current
≤ 50 mA
Housing material
Zinc diecast
Housing color
Light blue (RAL 5012)
Enclosure rating
IP54 (EN 60529, EN 60529/A2)
Protection class
III
Electrical safety
EN 62368
Вес
165 g
Dimensions (L x W x H)
50 mm x 40.3 mm x 29.6 mm
Readable code structures
2D codes
2D code types
Data Matrix ECC200, QR code
Code qualification
On the basis of ISO/IEC 16022, ISO/IEC 15415, ISO/IEC 15416, ISO/IEC 18004
Ethernet
✔ , TCP/IP
PROFINET
✔
EtherNet/IP™
✔
Serial
✔ , RS-232
CAN
✔
Function
SICK CAN sensor network CSN (CAN controller/CAN device, multiplexer/server)
CANopen
✔
Data transmission rate
20 kbit/s ... 1 Mbit/s
Optical indicators
9 LEDs (6 status displays, 2 LED alignment aids, 1 feedback spot)
Configuration software
SOPAS ET (version 2018.04 or higher)
Data storage and retrieval
Image and data storage via external FTP
EncoderFrequency
Max. 300 Hz
External illumination control
Via digital output (max. 24 V trigger)
Electromagnetic compatibility (EMC)
EN 61000-6-4:2007+A1:2011 / IEC 61000-6-3:2006+AMD1:2010 / EN 61000-6-2:2005-08
Vibration resistance
EN 60068-2-6:2008-02
Shock resistance
EN 60068-2-27:2009-05
Ambient operating temperature
0 °C ... +40 °C1)
Storage temperature
–20 °C ... +70 °C
Relative humidity
90 %, Non-condensing
EU declaration of conformity
✔
UK declaration of conformity
✔
ACMA declaration of conformity
✔
China RoHS
✔
cULus certificate
✔
BIS registration
✔
ESD conformity
✔
Information according to Art. 3 of Data Act (Regulation EU 2023/2854)
✔
