Murrelektronik
T-Coupler M12 male / 2x M12 female A-cod.
Prix hors TVA
Demander un devis
T-coupler Male straight – females straight M12 – M12, 4-pole Series connection Plastic housings with good resistance against chemicals and oils. The...
Poids
0,040 kg
Pays d'origine
DE
Désignation du modèle
MSA02NL0-BN-BN
Family construction form
M12
No. of poles
4
Coding
A
Gender
male
Mounting method
inserted, screwed, Shaking protection
Threaded hole
M12 x 1
Tightening torque
0,6 Nm
Width across flats
SW 13
Degree of protection (EN IEC 60529)
IP67
Operating voltage AC max.
60 V
Operating voltage DC max.
60 V
Current operating per contact max.
4 A
