Machine vision | sensingCam SEC310 | SEC310-A2G99DZ1ZZZ | Communication interface: REST API, Ethernet | Configuration software: Web server integrated | Shutter technology: Global-Shutter | Sensor resolution: 1,920 px x 1,080 px (2.1 MP) | Detection angle: 108° x 73° | Technology: 2D snapshot, streaming, event recording | Event recording video format: MP4 | Event recording buffer: 130 s at Full HD (1,920 x 1,080 pixels) @ 60 fps (primary stream) | Event recording trigger: Digital input or software trigger via REST API, TCP/IP
Product category
Streaming, flexible
Technology
2D snapshot, streaming, event recording
Sensor
CMOS monochrome
Shutter technology
Global-Shutter
Sensor resolution
1,920 px x 1,080 px (2.1 MP)
Working distance
0.15 m ... 10 m
Field of view
108° x 73°
Memory
4 GB, internal memory or FTP upload
Lighting
Not enabled
Lens
Integrated
Scan/frame rate
1 fps ... 60 fps, Primary stream
Video resolution
Full HD (1,920 x 1,080 pixels)
Video protocol
RTSP, MJPG
Real-time video transmission
Two individually configurable RTSP streams, one MJPEG stream and two MJPEG streams (WebSocket and HTTP/HTTPS)
Video compression
H.264, Add H.265, Motion JPEG, configurable compression level
Image format
JPEG, BMP
Trigger
Digital input or software trigger via REST API, TCP/IP
Event recording video format
MP4
Event recording buffer
130 s at Full HD (1,920 x 1,080 pixels) @ 60 fps (primary stream)
Event recording trigger
Digital input or software trigger via REST API, TCP/IP
Event recording duration
Up to 1,200 s
REST API
✔
Ethernet
✔ , TCP/IP
Remark
DHCP/static (default: 192.168.0.1)
Data transmission rate
1 Gbit/s, 1000Base-TX
Configuration software
Web server integrated
Supply voltage
10.8 V DC ... 30 V DC1)
Power consumption
Typ. 2 WMax. 10 W
Digital input, level
Active: 10 V ≤ UIN≤ UVInactive: UIN≤ 2 V
Protection class
III
Enclosure rating
IP65
Supply voltage & I/O
Connector M12, 8-pin, A-coded, 321 mm
Ethernet interface
M12 female connector, 8-pin, X-coded, 224 mm
-- 1
DA+
-- 2
DA-
-- 3
DB+
-- 4
DB-
-- 5
DD+
-- 6
DD-
-- 7
DC-
-- 8
DC+
Dimensions (W x H x D)
57.5 mm x 57 mm x 38 mm (without connection)
Housing material
Aluminum
Window material
Glass
Weight
250 g
Mounting
Four threads for M4 screwsOne slot for sliding nut
Ambient temperature, operation
–30 °C ... +50 °C
Ambient temperature, storage
–30 °C ... +60 °C
Permissible relative humidity
≤ 70 %
Shock resistance
150 m/s² EN 60068-2-27
Vibration resistance
EN 60068-2-6, EN 60068-2-64
ECLASS 5.0
27310205
ECLASS 5.1.4
27310205
ECLASS 6.0
27310205
ECLASS 6.2
27310205
ECLASS 7.0
27310205
ECLASS 8.0
27310205
ECLASS 8.1
27310205
ECLASS 9.0
27310205
ECLASS 10.0
27310205
ECLASS 11.0
27310205
ECLASS 12.0
27310205
ETIM 5.0
EC001820
ETIM 6.0
EC001820
ETIM 7.0
EC001820
ETIM 8.0
EC001820
UNSPSC 16.0901
43211731
EU declaration of conformity
✔
UK declaration of conformity
✔
ACMA declaration of conformity
✔
Moroccan declaration of conformity
✔
China RoHS
✔
cULus certificate
✔
Information according to Art. 3 of Data Act (Regulation EU 2023/2854)
✔
