Murrelektronik
RJ45 Push Pull male 0°/RJ45 Push Pull male 0° AIDA
Hind käibemaksuta
Küsi pakkumist
Ethernet CAT5 Male straight – male straight RJ45PP – RJ45PP, 4-pole Shielded Push Pull maximum length at channel transmission corresponds to 100 m...
Kaal
0,135 kg
Päritoluriik
DE
Mudeli tähistus
MSPAL0-PA-8p4c796_1.5
Cable length
1,50 m
Family construction form
RJ45
No. of poles
4
Gender
male
Mounting method
pluggable
Cable outlet
straight
Material
Zinc die-casting
Degree of protection (EN IEC 60529)
IP67, IP65
Operating voltage DC max.
60 V
Current operating per contact max.
1,5 A
Data transmission rate max.
100 Mbit/s
Transfer parameters
CAT5, Class D (ISO/IEC 11801:2002), (EN 50173-1)
