Ethernet CAT5e Male straight RJ45, 4-pole Shielded with cable sleeves Plastic housings with good resistance against chemicals and oils. The resistance to...
Weight
0,190 kg
Country of origin
DE
Model designation
MSRAL0-8p4c675_2.5
Cable length
2,50 m
Family construction form
free cable end
No. of poles
4
Gender
male
Mounting method
pluggable
Cable outlet
straight
Degree of protection (EN IEC 60529)
IP20
Stripping length (jacket)
20 mm
Operating voltage DC max.
60 V
Current operating per contact max.
1,5 A
Data transmission rate max.
100 Mbit/s
Transfer parameters
CAT5, Class D (ISO/IEC 11801:2002), (EN 50173-1)
