Product fulfills requirements according to UN/ECE R118 Cat6 Male straight – male straight RJ45 – RJ45, 8-pole Shielded without cable sleeves Further...
Kaal
0,036 kg
Päritoluriik
HU
Mudeli tähistus
MSRAL0-RA-8p8c790_0.3-S01
Cable length
0,30 m
Family construction form
RJ45
No. of poles
8
Gender
male
Mounting method
inserted
Cable outlet
straight
Material
PUR
Degree of protection (EN IEC 60529)
IP20
Operating voltage DC max.
60 V
Current operating per contact max.
1,5 A
Data transmission rate max.
10 Gbit/s
Transfer parameters
CAT6, Class EA (ISO/IEC 11801:2002), (EN 50173-1)
