Ethernet Male straight RJ45, 8-pole Field-wireable Shielded Protection IP20 The resistance to aggressive media should be individually tested for your...
Weight
0,029 kg
Country of origin
PL
Model designation
MSRAL0-8p8C Ethernet
Family construction form
RJ45
No. of poles
8
Material contact
Copper alloy
Operating voltage AC
50 V
Operating voltage DC
50 V
Operating current max.
1,75 A
Data transmission rate max.
1.000 Mbit/s
Transfer parameters
CAT5e (ANSI/TIA/EIA-568-B.2-2001), CAT5 Class D according to ISO/IEC 11801
Connection cross section min.
0,14 mm²
Connection cross section max.
0,25 mm²
AWG number min.
26
AWG number max.
24
