Control electronics for proportional valves 18...32 V DC, smoothed (2200 µF/1 A) Screw terminals Start-up: 1 s The amplifier regulates the current supply to...
Weight
0,094 kg
Country of origin
CZ
Model designation
Proportional amplifier 24VDC 1 sec
Operating voltage DC min.
18 V
Operating voltage DC max.
32 V
Operating current max.
2,5 A
Current consumption max.
50 mA
Resistance input min.
200 kΩ
Control voltage DC min.
0 V
Control voltage DC max.
10 V
Output voltage adjustable
No
Output voltage DC
24 V
Output current
2,5 A
Status indication LED
green
Connection
Screw terminals SK
