Murrelektronik
MVP12 plastic DI8 DO8 IO-Link I/O module
Price excluding VAT
Request a quote
Compact module IO-Link V1.1 Connection cables are in the online shop under "Connection Technology". Housing fully potted.
Weight
0,200 kg
Country of origin
CZ
Model designation
MVP12 DI8 DO8 IOL
Input filter time
1 ms
Type input
PNP (EN 61131-2) Type 3
Output current per pin max.
0,4 A
Overload resistant
Yes
Short-circuit protected
Yes
IO-Link type
Device
Port Class
B
IO-Link revision ID
V1.1
IO-Link transmission rate
COM2 (38.4 kbit/s)
IO-Link cycle time min.
2,3 ms
Short circuit diagnosis
Yes
Overload diagnosis
Yes
