6-way, 5-pole Spring clamp plug-in terminals Potential separation as option Plastic housings with good resistance against chemicals and oils. The resistance...
Poids
0,178 kg
Pays d'origine
DE
Désignation du modèle
MVP12K-LN6F
Operating voltage DC
24 V
Current operating per contact max.
4 A
Total current at 1 time current feed-in max.
8 A
Total current at 2 times current feed-in max.
16 A
Number of signals per port
2
Connection cross section max.
1,5 mm²
AWG number max.
16
Connection
Spring clamp terminals FK
Mounting set
M12 x 1
Degree of protection (EN IEC 60529)
IP67
Additional condition protection degree
mounted, screwed
Flame resistance
flame retardant
