Murrelektronik
MVP12, 6XM12, 5POLE, PLUG. CAP SCT.
Price excluding VAT
Request a quote
6-way, 5-pole Screw plug-in terminals Potential separation as option with LED for digital PNP-signals 24 V DC Plastic housings with good resistance against...
Weight
0,123 kg
Country of origin
DE
Model designation
MVQ6-U
Operating voltage DC
24 V
Current operating per contact max.
4 A
Total current at 1 time current feed-in max.
8 A
Total current at 2 times current feed-in max.
16 A
Number of signals per port
2
Connection cross section max.
1,5 mm²
AWG number max.
16
Connection
Screw plug-in terminals
Mounting set
M12 x 1
Degree of protection (EN IEC 60529)
IP67
Additional condition protection degree
mounted, screwed
Flame resistance
flame retardant
