MTS SINGLE-PHASE SAFETY TRANSFORMER
MTS SINGLE-PHASE SAFETY TRANSFORMER
MTS SINGLE-PHASE SAFETY TRANSFORMER
Murrelektronik

MTS SINGLE-PHASE SAFETY TRANSFORMER

SKU: 866180 Available to order
Price excluding VAT
Request a quote

Request a quote

    Single-phase - Control and Isolation Transformers 30 VA Isolation class T 40/B Other voltages on request.

    Weight
    1,100 kg
    Country of origin
    CZ
    Model designation
    MTS 0030-230/24 Ua max. 26,3V FK
    Power frequency
    50 ... 60 Hz
    Input voltage AC
    230 V
    Nominal input voltage AC
    230 V
    Current input AC
    0,22 A
    Nominal current AC
    230 V
    Max. inrush current
    1,52 A
    Short-circuit current
    2,21 A
    Output voltage adjustable
    No
    Output voltage AC
    24 V
    Power rating AC max.
    30 VA
    Insulation test voltage input - output
    3,8 kV
    Height
    92 mm
