Form CI (9.4 mm) 24 V AC ±20% / DC ±25% LED and suppression Screw, Stainless Steel 1.4404 (V4A) Further cable lengths on request. Plastic housings with...
Вес
1,250 kg
Страна происхождения
CZ
Обозначение модели
MSUDK-QB1Z-616_20.0-SV-S04
Cable length
20,00 m
Threaded hole
M3x31
Tightening torque
0,4 Nm
Degree of protection (EN IEC 60529)
IP67
Stripping length (jacket)
50 mm
Drop-out delay time max.
20 ms
Operating voltage AC
24 V
Operating voltage AC min.
19,2 V
Operating voltage AC max.
28,8 V
Operating voltage DC
24 V
Operating voltage DC min.
18 V
Operating voltage DC max.
30 V
