Adapter M12 – M12 4-pole
Weight
0,015 kg
Country of origin
DE
Model designation
MSB04L0-A-T 2/4
Operating voltage AC max.
24 V
Operating voltage DC max.
24 V
Current operating per contact max.
4 A
Tightening torque
0,6 Nm
Mounting set
M12 x 1
Degree of protection (EN IEC 60529)
IP67
Additional condition protection degree
inserted, screwed
Rated insulation voltage
800 V
Material housing
PUR
Locking material
Zinc die-casting
Coating locking
Nickeled
Mounting method
inserted, screwed, Shaking protection
