Murrelektronik
MEN POWER SUPPLY 1/2-PHASE, SMOOTHED
Price excluding VAT
Request a quote
Current: 2.5 A Output rating: 60 W without DIN-rail adapter This power supply units meet the (EN 61000-3-2) standard for harmonic current. For any mounting...
Weight
2,100 kg
Country of origin
CZ
Model designation
MEN 2,5-115-230 +-10V/24VDC
Security level
SELV
Power frequency
50 ... 60 Hz
Nominal input voltage AC
115 V … 230 V
Input voltage 1 AC min.
105 V
Input voltage 1 AC max.
125 V
Input voltage 2 AC min.
220 V
Input voltage 2 AC max.
240 V
Nominal current AC
1 A @ 115 V,0.5 A @ 230 V
Characteristic back-up fuse
Inertia
Fuse protection 1 primary side external
1.6 A @ 115 V AC
Fuse protection 2 primary side external
0.8 A @ 230 V AC
Output voltage adjustable
No
