Xtreme - Outdoor Male straight – female 90° 6...230 V AC/DC without components compatibel to Deutsch DT06-4S MSUD A Plastic housings with good resistance...
Вес
0,075 kg
Страна происхождения
CZ
Обозначение модели
MSKL0-TD-T754_0.6-S72
Cable length
0,60 m
Family construction form
Amphenol AT06-4S
No. of poles
4
Mounting method
inserted, screwed
Material contact
Copper alloy
Coating contact
nickel plated
Degree of protection (EN IEC 60529)
IP68
Operating voltage AC min.
6 V
Operating voltage AC max.
230 V
Operating voltage DC min.
6 V
Operating voltage DC max.
230 V
Current operating per contact max.
8 A
