Xtreme - Outdoor Male straight – female 90° 12...24 V DC MSUD A compatibel to Deutsch DT06-4S without components Plastic housings with good resistance...
Вес
0,255 kg
Страна происхождения
DE
Обозначение модели
MSKL*-TD4pP-*754_5.0-S72
Cable length
5,00 m
Family construction form
Amphenol AT06-4S
No. of poles
2
Mounting method
inserted, screwed
Material contact
Copper alloy
Coating contact
nickel plated
Degree of protection (EN IEC 60529)
IP68
Operating voltage DC min.
12 V
Operating voltage DC max.
24 V
Current operating per contact max.
4 A
Status indication LED
yellow
Tightening torque
0,4 Nm
