Xtreme - Outdoor Male straight – female straight 6...230 V AC/DC 4-pole without components compatible to Deutsch DT06-4S and Deutsch DT04-4P Plastic...
Вес
0,957 kg
Страна происхождения
DE
Обозначение модели
MSTE4L0-TD4-TP07_10.0-S72
Cable length
10,00 m
Family construction form
Amphenol AT04-4P
No. of poles
4
Mounting method
inserted
Material contact
Copper alloy
Coating contact
nickel plated
Operating voltage AC min.
6 V
Operating voltage AC max.
230 V
Operating voltage DC min.
6 V
Operating voltage DC max.
230 V
Current operating per contact max.
8 A
Status indication LED
No
