Xtreme - Outdoor Junior Power Timer (AMP) Amphenol AT06-2S or Deutsch DT06-2S Female straight – male straight 6...230 V AC/DC without components Stainless...
Weight
0,141 kg
Country of origin
DE
Model designation
MSTAL0-TD4pP-*754_2.5-S72
Cable length
2,50 m
Family construction form
Amphenol AT06-4S
No. of poles
2
Mounting method
inserted
suitable for corrugated tube (internal Ø)
10 mm
Degree of protection (EN IEC 60529)
IP68
Operating voltage AC min.
6 V
Operating voltage AC max.
230 V
Operating voltage DC min.
6 V
Operating voltage DC max.
230 V
Current operating per contact max.
4 A
Status indication LED
No
