Digital inputs/outputs DI4 - 1.6 A DO4 - 2 A - 4× M12 Double assignment of M12 females, PIN 2 + 4 Sensor supply from external 24 V DC Connection cables are...
Вес
0,240 kg
Страна происхождения
CZ
Обозначение модели
MASI67 DI4/1,6A DO4/2A 4xM12
Norm operating voltage
IEC/EN 61131-2
Total current max.
8 A
Operating voltage UA DC
24 V
Bus voltage AS-Interface DC min.
26,5 V
Bus voltage AS-Interface DC max.
31,6 V
Current consumption AS-i port max.
50 mA
Current carrying capacity max.
1,6 A
Short-circuit protected
Yes
Overload resistant
Yes
Type input
for 3-wire sensors or mechanical switches, PNP
Output current per pin max.
2 A
Address setting type
Addressing socket, Master
