Murrelektronik
M8 panel feed through male / female 0° A-cod.
Цена без НДС
Запросить цену
Control cabinet entry system Male - female M8, 4-pole Rear mounting Shielded
Вес
0,035 kg
Страна происхождения
DE
Обозначение модели
MSFL0-H-T Schaltschrankdurchführung
Family construction form
M8
No. of poles
4
Material contact
Copper alloy
Operating voltage DC
60 V
Current operating per contact max.
4 A
Status indication LED
No
Mating cycles min.
100
Degree of protection (EN IEC 60529)
IP67
Additional condition protection degree
inserted, screwed
Pollution Degree
3
Overvoltage category (EN 60950-1)
II
Rated surge voltage
1,5 kV
