Male straight M8, 4-pole Shielded Screw terminals Connection cross section: 0.14...0.5 mm² The resistance to aggressive media should be individually tested...
Kaal
0,053 kg
Päritoluriik
DE
Mudeli tähistus
M8 STECKER GER.4,0..5,5 4pol.gesch.
Family construction form
M8
No. of poles
4
Coding
A
Gender
male
Mounting method
inserted, screwed, Shaking protection
Threaded hole
M8 x 1
Cable outlet
straight
Material contact
Brass
Coating contact
gold plated
Degree of protection (EN IEC 60529)
IP67
Operating voltage DC max.
30 V
Current operating per contact max.
4 A
