IDC terminals Male straight M8, 4-pole Connection cross section: 0.14...0.34 mm² Sealing comb included in delivery
Вес
0,015 kg
Страна происхождения
DE
Обозначение модели
MSHL0-AC-T MOSA 0,14-0,34qmm
Family construction form
M8
No. of poles
4
Gender
male
Mounting method
inserted, screwed, Shaking protection
Width across flats
SW9
Cable outlet
straight
Material
PA
Material contact
Copper alloy
Degree of protection (EN IEC 60529)
IP67
Operating voltage AC max.
32 V
Operating voltage DC max.
32 V
Current operating per contact max.
4 A
