Murrelektronik
M8 female receptable 0° D-cod. rear
Price excluding VAT
Request a quote
PCB connectors Female straight M8, 4-pole D-coded Shielded THT-solder connection Rear mounting
Weight
0,008 kg
Country of origin
CZ
Model designation
MSDGFH-T-PCB
Family construction form
M8
No. of poles
4
Coding
D
Width across flats
SW14
Material contact
Brass
Coating contact
nickel plated
Operating voltage AC
50 V
Operating voltage DC
60 V
Current operating per contact max.
4 A
Data transmission rate max.
100 Mbit/s
Transfer parameters
CAT5, Class D (ISO/IEC 11801:2002), (EN 50173-1)
Tightening torque
0,6 Nm
