Murrelektronik
M12 Power male 0° T-cod. screw terminal
Price excluding VAT
Request a quote
Power Male straight M12, 4-pole T-coded Screw terminals Sealing range (cable Ø): 8...10 mm Plastic housings with good resistance against chemicals and oils....
Weight
0,027 kg
Country of origin
DE
Model designation
MSWATL0-T
Family construction form
M12P
No. of poles
4
Coding
T
Operating voltage AC max.
63 V
Operating voltage DC max.
63 V
Current operating per contact max.
12 A
Connection cross section max.
1,5 mm²
Tightening torque
0,6 Nm
Mounting set
M12 x 1
Width across flats
SW18
Degree of protection (EN IEC 60529)
IP67
Additional condition protection degree
inserted, screwed
