Murrelektronik
M12 Power L-cod. male 0° / M12 A-cod. female 90°
Hind käibemaksuta
Küsi pakkumist
Customized printing and packaging M12 Power Male straight L-coded Female 90° M12, 2-pole, A-coded The resistance to aggressive media should be individually...
Kaal
0,111 kg
Päritoluriik
DE
Mudeli tähistus
MSDL0-WAL-C444_1.0-XH
Cable length
1,00 m
Family construction form
M12
No. of poles
4
Coding
A
Threaded hole
M12 x 1
Tightening torque
0,6 Nm
Width across flats
SW13
Operating voltage AC max.
63 V
Operating voltage DC max.
63 V
Current operating per contact max.
4 A
Status indication LED
No
Degree of protection (EN IEC 60529)
IP67, IP65
