Murrelektronik
M12 Power L-cod. 5pol. male 0° / female 0°
Prix hors TVA
Demander un devis
Customized printing and packaging Power Male straight – female straight M12 – M12, 5-pole with cable sleeves Plastic housings with good resistance...
Poids
0,086 kg
Pays d'origine
DE
Désignation du modèle
MSWBLL0-WAL-UP09_0.3-XH
Cable length
0,30 m
Family construction form
M12P
No. of poles
5
Mounting method
inserted, screwed
Material contact
Copper alloy
Coating contact
gold plated
Operating voltage DC max.
63 V
Current operating per contact max.
12 A
Pollution Degree
3
Rated surge voltage
1,5 kV
Material group (IEC 60664-1)
I
Operating temperature min.
-25 °C
