Power Flange female M12, 4-pole L-coded Front mounting with multi-strand wire The resistance to aggressive media should be individually tested for your...
Вес
0,061 kg
Страна происхождения
DE
Обозначение модели
MSWBLFV-T997_0.2
Cable length
0,20 m
Family construction form
M12P
No. of poles
4
Coding
L
Mounting method
inserted, screwed
Threaded hole
M12 x 1
Tightening torque
0,6 Nm
Width across flats
SW17
Material contact
Copper alloy
Coating contact
gold plated
Degree of protection (EN IEC 60529)
IP67, IP65
Operating voltage DC max.
63 V
