Murrelektronik
M12 Power female 0° L-coded / Push Pull Power AIDA
Hind käibemaksuta
Küsi pakkumist
Male straight – female straight M12 L-coded - PPP, 5-pole Push Pull Power with cable sleeves Plastic housings with good resistance against chemicals and...
Kaal
0,180 kg
Päritoluriik
CZ
Mudeli tähistus
MSWBLL0-WPA-UP09_0.45
Cable length
0,45 m
Family construction form
M12P
Gender
female
Cable outlet
straight
No. of poles
5
Degree of protection (EN IEC 60529)
IP67
Tightening torque
0,6 Nm
Mounting method
Push Pull
Coating contact
gold plated
Thread
M12 x 1
suitable for corrugated tube (internal Ø)
16,4 mm
Coding
A
