Murrelektronik
M12 Power female 0° L-cod. with cable
Price excluding VAT
Request a quote
Power Female straight M12, 5-pole L-coded with cable sleeves Plastic housings with good resistance against chemicals and oils. The resistance to aggressive...
Weight
1,653 kg
Country of origin
DE
Model designation
MSWBLL0-UP04_12.5
Cable length
12,50 m
Family construction form
free cable end
No. of poles
5
Coding
L
Gender
female
Mounting method
inserted, screwed, Shaking protection
Threaded hole
M12 x 1
Tightening torque
0,6 Nm
Width across flats
SW17
Cable outlet
straight
suitable for corrugated tube (internal Ø)
12 mm
Material
PUR
